Tap & drill guide
How to Use the Tap & Drill Size Chart
A step-by-step guide for engineers and machinists
A tap drill chart lists the recommended hole diameter before threading to achieve the target thread engagement — typically 75% with cutting taps in ductile materials. The right drill prevents undersized holes (tap breakage) and oversized holes (weak threads). The chart covers metric, UNC, UNF, and NPT threads in one filterable place.
Step 1 — Read the thread callout on the drawing
Start with the exact specification: metric (M6 × 1.0, M8 × 1.25), inch UNC (1/4-20, 5/16-18), UNF (1/4-28, 5/16-24), or NPT for fittings. Note thread class if shown (2B/3B), blind vs through depth, and whether the process requires a cutting or forming tap. Cutting taps evacuate chips and need a smaller hole; forming taps displace material and need a larger hole.
Step 2 — Confirm tap type and thread percentage
Many drawings assume a cutting tap at ~75% engagement — enough for typical fasteners without overloading the tool. Lower percentages mean a slightly larger hole and easier tapping; higher percentages increase torque. If the print does not specify percentage, align with your CNC vendor during DFM review before releasing toolpaths.
Step 3 — Look up the tap drill in the chart
Open the Tap & Drill Size Chart and filter by thread family. Use the tap drill column — not the clearance column. Common references: 1/4-20 UNC is often near a #7 drill; M6 × 1.0 metric is near 5.0–5.1 mm. NPT threads follow pipe tables, not the straight-thread formula.
Step 4 — Match to a stocked drill
Charts return a calculated diameter; shops stock number, letter, fractional, and metric drills. Round to the nearest available drill that meets engagement, usually rounding up slightly for easier tapping. Cross-check against the Drill Bit Size Chart so programming and inspection use the same label.
Do not mix tapped holes with clearance holes: clearance lets the bolt pass without cutting threads in the part; tap drill sizes the hole before tapping or thread milling. If the screw passes through, use clearance values; if the part needs internal threads or an insert, use tap drill values and call out tap type on the drawing.
For non-standard threads, forming taps, or comparing 65% vs 75%, use the Tap Drill Size Calculator. It returns diameters in mm and inches plus the nearest standard drill.
Diameter is not the only variable: blind holes need drill depth below the thread floor; in stainless or titanium a slightly larger drill can reduce tap breakage. Before quoting, align thread notes across model, PDF, and BOM — inconsistencies cause DFM holds. Pair this guide with the CNC Design Guide and ISO 2768 chart, then request a quote with STEP, quantity, and material.
The correct tap drill matters more than most teams expect. Too small risks tap breakage; too large reduces clamp load. Bookmark the interactive chart for UNC, UNF, metric, and clearance reference in one place.
